| Basic Information | |
| Truck Brands | HOWO |
| Drive type: | 4x2 |
| engine: | WP4.6NQ240E62 / WP7H270E62 |
| Vehicle length: | 8600 / 9000mm (actual length may vary) |
| Vehicle width: | 2450 / 2500mm (actual length may vary) |
| Vehicle height: | Based on actual height |
| wheelbase | 4500 / 5000 mm |
| Maximum speed: | 89km/h |
| Fuel tank capacity: | 200L |
| Energy type: | diesel fuel |
| beam structure | (8+5+8) *303mm |
| chassis suspension | Standard springs (10 in the front + 12 in the back) |
| Engine parameters | |
| Engine model: | WP4.6NQ240E62 / WP7H270E62 |
| Engine power | 176kW / 198kW |
| Engine horsepower | 240 / 270 horsepower |
| Number of cylinders: | 6 cylinders |
| Fuel type: | diesel fuel |
| Cylinder arrangement: | inline |
| Displacement: | 4.6L / 7L |
| Emission standards: | European VI |
| Transmission parameters | |
| Gearbox brand: | Sinotruk |
| Transmission model: | HW11708STC |
| Gearbox Series | HW8 series |
| forward gear | 8 forward gears |
| Reverse gear | 1 reverse gear |
| Gear shifting method: | Manual transmission |
| Chassis parameters | |
| Driver's cab: | TX Single Sleeper Cab |
| Driver's seat direction | left |
| Passenger capacity: | 2 people |
| Chassis parameters | |
| Front axle allowable load: | 7500 kg |
| Rear axle allowable load: | 13000 kg |
| tire | |
| Tire specifications: | 10.00R20 tires (18PR) |
| Number of tires: | 6+1 |
| Crane Information | |
| Crane Brands | XCMG |
| Crane Model | SQS200-4 |
| Number of hydraulic telescopic rods | 4 |
| Maximum lifting weight | 8000kg |
| Maximum hydraulic elongation | 13.5m |
| Rotation angle | 360° |
| Work pressure | 26Mpa |
| Hydraulic oil tank capacity | 200L |
| Crane self-weight | 3350kg |
| Forward leg stride | 2332-5700mm |
| Pallet Information | |
| pallet length | 5600/ 5800 / 6000 (Special sizes can be customized) |
| pallet width | 2400/ 2450 / 2500 (Special sizes can be customized) |
| pallet material | carbon steel patterned plate |
| pallet thickness | 3mm / 5mm |
| Beam spacing | 25-30cm / 30-35cm |
| Main bearing capacity | 18,000 kg - 25,000 kg |
