Your products's number
| Basic Information | |
| Truck Brands | HOWO |
| Drive type: | 4x2 |
| Vehicle length: | 7600 / 8000 (subject to actual length) |
| Vehicle width: | 2450 / 2500mm (actual length may vary) |
| Vehicle height: | Based on actual height |
| wheelbase | 3600 / 3800 / 4200 / 4500 mm |
| Maximum speed: | 89km/h |
| Fuel tank capacity: | 120L |
| Energy type: | diesel fuel |
| Engine parameters | |
| Engine model: | YC4E140-33 |
| Engine power | 103kW |
| Engine horsepower | 140 horsepower |
| Number of cylinders: | 4-cylinder |
| Fuel type: | diesel fuel |
| Cylinder arrangement: | inline |
| Emission standards: | Europe II |
| Transmission parameters | |
| Gearbox brand: | Sinotruk |
| Transmission model: | WLY6TS55C |
| forward gear | 5 forward gears |
| Reverse gear | 1 reverse gear |
| Gear shifting method: | Manual transmission |
| Chassis parameters | |
| Driver's seat direction | Left/Right |
| Passenger capacity: | 5 people |
| Chassis parameters | |
| Front axle allowable load: | 2600 kg |
| Rear axle allowable load: | 7200 kg |
| tire | |
| Tire specifications: | 8.25R16 18PR all-steel tires |
| Number of tires: | 6+1 |
| Crane Information | |
| Crane Brands | XCMG |
| Crane Model | SQS |
| Number of hydraulic telescopic rods | 4 |
| Maximum lifting weight | 5000Kg |
| Maximum hydraulic elongation | 11.48m |
| Rotation angle | 360° |
| Work pressure | 26Mpa |
| Hydraulic oil tank capacity | 90L |
| Crane self-weight | 1350kg |
| Forward leg stride | 2187-4664mm |
| Pallet Information | |
| pallet length | 3800/4000 (Special sizes can be customized) |
| pallet width | 2400/2450 (Special sizes can be customized) |
| pallet material | carbon steel patterned plate |
| pallet thickness | 3mm / 5mm |
| Beam spacing | 25-30cm / 30-35cm |
| Main bearing capacity | 8000kg - 1000kg |
